Inspcetion type

An overview, UHZ - 25 inspcetion level gauge and UHZ - 27 top float liquid level gauge, remote transmission, liquid level transmitter can be configured to achieve liquid level signal remote transmission of the display/a.

Second, the structure principle of MY type analog liquid level transmitter, consists of two parts, liquid level sensor and signal converters. Liquid level sensor installed in the phi 20 several dry reed pipe of stainless steel protective tube and some resistance, protection pipe clamp on the outside of measuring tube (tube) main body; Signal converter is composed of electronic modules, placed at the top of the sensor or explosion-proof terminal box at the bottom of the three, main technical parameters, range 1: be determined by measuring range H; Error: 2, plus or minus 10 mm; 3, the output signal: 4 ~ 20 ma. DC (two wire system); 4, load resistance: 550 Ω or less; 5, power supply voltage: 24 v DC; 6, outlet: M20 x 1.5 (in); 7, environment temperature: - 40 ~ + 60 ℃; 8, explosion-proof grade: d Ⅱ BT1-4; 9, shell protection grade: IP65.

Three, maglev ball liquid level meter, etc

Maglev ball liquid level meter has simple structure, convenient use, stable performance, long service life, easy installation and maintenance, etc.

Four, the application of maglev ball liquid level gauge

Mainly is widely used in oil processing, food processing, chemical industry, water treatment, pharmaceutical, electric power, papermaking, metallurgy, level measurement in the field of ship and boiler etc.

The floating

Floating double cavity liquid level gauge (viscous medium level meter), is the technology that USES JKS company of Canada, is a kind of for high viscous medium level measurement instrument of special use researched and developed. The product was conducted on the basis of the inspcetion liquidometer technology upgrading, completely overcome the inspcetion level gauge of viscous medium long measurement is accurate and the liquid and the float inside the cavity adhesion, maintenance difficulties, and many other ills.

Floating within the magnetic level gauge is a kind of double cavity liquid level meter, and the measured medium on the magnetic panel cavity is isolated, container end and float inside the cavity after special processing, make sure the float to transfer to follow the change of liquid level linear magnetic panel, accurately and clearly indicates that the height of liquid level. It can be the scene shows, both far eastone alarm control and output signals. Is used a pluripotent liquid level measuring instrument, measuring viscous medium is the best liquid level measuring instrument.

Magnetic flap

UHZ - 45 high temperature and high pressure magnetic flap for broadening the UHZ series magnetic level gauge is my company the use of the liquid level meter, turning more broadly meet the requirements of electric power, heat supply, gas supply and other industries, adopt unique cooling way, effectively control the working temperature of the medium instrument, to avoid the magnetic components under the condition of high temperature demagnetization, ensure reliable work, measurable high temperature 450 ℃, high-pressure 25 mpa, a leading position among the same industry at home.

The level of the liquid level gauge is suitable for high temperature and high pressure liquid containers, the position of the measurement and control. Clearly indicates that the height of liquid level, direct display striking, indicator and completely isolated storage tank, the use of safe, reasonable design, simple structure, convenient installation and reliable, stable performance, long service life, low maintenance cost, easy installation and maintenance, etc.

Users can according to the requirements of the project, cooperate with remote transmitter use, can be realized on the digital display, as well as the standard of 4 ~ 20 ma output far eastone electrical signals, to match the recording instrument, or the needs of the industrial process control. Can also be used with magnetic control switch or close to switch, etc, the liquid level monitoring alarm and control into the liquid equipment.

Technical parameters

Measuring range: 200... ~ 15000 ㎜ (more than 6000 mm or transportation conditions are not allowed to exceed the length of the liquid level meter can be procurement section)

Display precision: plus or minus 10 mm;

Pressure of work: 6.3, 10.0, 16.0, 10.0 MPa;

Medium temperature: - 20 ℃ ~ 450 ℃;

Medium density: p. 0.5 g/cm3;

Medium density difference: p. 0.15 g/cm3 (measuring the position)

Medium viscosity: 0.4 Pa s. or less;

Process connections: 3/4 "/ 25 PN1.0 (executive standard HG20592 ~ 20635-97), if you need other standard can be made according to customer's requirement.

Liquid material: 316 ss, 316 l, and so on

(according to the chemical properties and the use of medium temperature pressure selection).

Float material: 316 ss, 316 l, titanium, etc.

Input type

Level gauge

Level gauge

Input type level gauge (static pressure gauge/liquid level transmitter, liquid level sensor/water level sensor) is a kind of measuring the pressure of liquid level sensor. HAKK inputting type liquid level transmitter - 500 static pressure (gauge) is based on the measured hydrostatic principle of proportional to the height of the liquid, USES the overseas advanced isolation diffusion silicon sensing element or sensitive ceramic capacitance pressure sensor, the static pressure is converted to electrical signals, after temperature compensation and the linear correction, converted into a standard electrical signals (usually 4 ~ 20 ma / 1 ~ 5 VDC).
